Resolved Questions Bookmark and Share
Yan

QR Code encoding the special characters such as &, # or '


Sometimes a company name will have special symbol such as &. For example, P&G. if the QR code has this, the string after the & will be chopped off.

Is there a way to encode this kind symbol?

The way we are using is http://ourservername/IDAutomation/IDAutomationStreamingQRCode.aspx?I=1BMP&barcode=00123456^P&G^Yan^Ton" and the data after & will be chopped off when read it.

Please advise.

Thanks

Operating System: Windows 7

Application: Crystal Report

11-12-14     1707 day(s) ago

  Report Abuse



James

Best Answer

It seems Crystal is filtering out any form of the &. You might have to contact SAP and ask if there is a separate character or a way around this limitation of Crystal Reports.

Posted 1707 day(s) ago

()
()
  Report Abuse

Find Interesting

Email to Others

Bookmark

Subscribe to Answer Alert
No comments yet.     Be the first to comment.
Other Answers (9)

Yan
this is the one I generated in Crystal report (screenshot) when using the same url. it is different from the one generated in a browser.

please let me know.

Thanks

Yan


Posted 1707 day(s) ago

()
()
   Report Abuse

Yan
Hi James:
I looked at the one from http://bcgen.com/demo/IDAutomationStreamingQRCode.aspx?I=1BMP&D=00123456^P%26G^Yan^Ton from the browser, and the one I generated from my crystal report 11 by pasting this link to the crystal report 11. they are different. the one from browser works but the one from crystal report does not work.

is there anything I can do to make it work in crystal same as the one in browser? what I should set for the report? I thought they should work the same, but it seems like not.

Yan

Posted 1707 day(s) ago

()
()
   Report Abuse

James
Since the forum does not show the URL correctly, here is the hyperlink. That will show the exact URL call made.

Posted 1707 day(s) ago

()
()
   Report Abuse

Yan
Hi, this bar code works with our scanner. and it shows the correct data.

but the QR code generated using http://bcgen.com/demo/IDAutomationStreamingQRCode.aspx?I=1BMP&D=00123456^P%26G^Yan^Ton does not work. it only shows Demo 00123456^P

how did you generate the following QR code?

Yan



Posted 1707 day(s) ago

()
()
   Report Abuse

James
Using this barcode:


If you get anything else but (ignoring the DEMO<CR><LF>, since it's a demo product):

00123456^P&G^Yan^Ton

Then it is your scanner (contact the manufacturer or refer to its manual), since the barcode is properly encoded.

Although the barcode is not proprietary to a specific scanner, we invite you to consider the SC7-USB which has many options and a feature called Print Quality Assessment, which gives graded information about 2D barcodes.


Posted 1707 day(s) ago

()
()
   Report Abuse

Yan
I tried to use parameter D and still get the same result 00123456^P

I also tried to use your demo site http://bcgen.com/demo/IDAutomationStreamingQRCode.aspx?I=1BMP&D=00123456^P%26G^Yan^Ton

and I got the same result 00123456^P

Please advise.

Thanks

Posted 1707 day(s) ago

()
()
   Report Abuse

James
The parameter for the DataToEncode is D=. When properly encoded (for the part after IDAutomationStreamingQRCode.aspx?):

I=1BMP&D=00123456^P%26G^Yan^Ton

It scans as:

00123456^P&G^Yan^Ton

Posted 1707 day(s) ago

()
()
   Report Abuse

Yan
it does not work when I replace & with %26. http://ourservername/IDAutomation/IDAutomationStreamingQRCode.aspx?I=1BMP&barcode=00123456^P%26G^Yan^Ton

the data scanned is 00123456^P

Please let me know what else I should change.

Thanks

Yan

Posted 1707 day(s) ago

()
()
   Report Abuse

James
Covered in the Barcode Streaming Product Does Not Encode Certain Characters post, the & symbol is reserved and can be represented with %26 in a URL call (this is shown to match the post):


The idea is the same with QR-Code URLs:

Posted 1707 day(s) ago

()
()
   Report Abuse
